1GE GPON ONU | Single Port Gigabit Optical Network Terminal | ITU-T G.984 Compliant
Product Overview
The Flypon 1GE GPON ONU is a cost-optimized Optical Network Terminal designed to meet the rigorous demands of modern Fiber-to-the-Home (FTTH) and Fiber-to-the-Building (FTTB) deployments. Fully compliant with the ITU-T G.984 GPON standard, this GPON ONU provides a robust 2.488 Gbps downstream and 1.244 Gbps upstream link, terminated by a full 1 Gigabit Ethernet port. It is the definitive solution for ISPs seeking a reliable, low-maintenance CPE for high-speed residential broadband delivery.
Key Features
· Full GPON Compliance (ITU-T G.984): Built with a dedicated GPON MAC chipset, this 1GE GPON ONU ensures seamless interoperability with leading OLT vendors including Huawei, ZTE, Nokia (Alcatel-Lucent), and Calix. Supports advanced GPON features like FEC (Forward Error Correction) and 128-bit AES encryption.
· High Optical Power Budget (Class B+): The GPON ONU optics are designed for Class B+ performance, supporting a maximum optical path loss of up to 28dB and a transmission distance of 20KM. This ensures reliable connectivity even at the edge of the PON distribution network.
· True Gigabit LAN Performance: Equipped with 1 x 10/100/1000Mbps auto-adaptive RJ45 port, this GPON ONT delivers wire-speed throughput, eliminating the LAN bottleneck found in older Fast Ethernet models.
· OMCI & TR-069 Management: The 1GE GPON ONU supports standard OMCI (ONT Management and Control Interface) for remote configuration, fault management, and performance monitoring. Optional TR-069 support is available for seamless integration into ACS auto-configuration servers.
Technical Specifications:
1GE GPON ONU – High-Performance Gigabit Terminal for FTTH Networks
· Optical Interface: SC/APC or SC/UPC (Single Fiber)
· Standards Compliance: ITU-T G.984.1/2/3/4, G.988 OMCI
· Data Rate: 2.488 Gbps Downstream / 1.244 Gbps Upstream
· Wavelength: TX 1310nm, RX 1490nm
· Optical Budget: Class B+ (28dB typical)
· Downlink Interface: 1 * 10/100/1000Base-T RJ45
· Power Consumption: < 3W
· Operating Temperature: -5°C to 50°C
- Product Feature
•Plug and play, integrated auto-detecting, auto-configuration, and auto firmware upgrade, etc.
>Integrated OMCI remote configuration and maintenance function.
>Functions like transceiver diagnostic monitoring, transmitter disable, etc.
>Fully compatibility with OLT based on Broadlight/Broadcom chipset.
>Support port monitoring, port mirroring, port rate limiting, port SLA, etc.
>Support auto polarity detection of Ethernet ports (AUTO MDIX).
>Support router
Port Feature
>1 EPON port (uplink 1.25Gbps, downlink 1.25Gbps)
>1 10/100/1000M port
PhysicalFeature
>Power supply: 12VDC
>Power consumption: 4W
>Dimension: 115mm*30mm*90mm（W*H*D）
>Net weight < 0.4Kg
>Working temperature:0～55℃
>Storage temperature: -30～60℃
>Relative humidity: 10～90% (non-condensing)
Our Company
Company Profile
Shenzhen Feituo Technology Technology Co., Ltd. was established in 2016 by senior technicians engaged in the optical communication industry and have more than ten years of experience in PON R&D and production. Specializing in providing customers with XGS-PON/XGPON/GPON/EPON ONU and OLT optical communication products R&D, production, sales and technical OEM/ODM services, the main products are: XGS-PON/XGPON/GPON/EPON ONU and OLT, optical fiber transceivers, optical fiber switches, voice gateways, wireless APs, optical fiber patch cords, optical splitters and other passive optical accessories.
Company advantages
The company has many excellent industry senior talents, mature market channels and good business reputation, since our products entered the market, with reliable product quality, reasonable market price, high-quality technical services quickly opened the market, received good feedback from customers, business has spread to Southeast Asia, Europe, America more than 30 countries and regions around the world.
Technology
We provide professional technicians to support customers' pre-sales and after-sales services, one-on-one guidance for customers to debug the computer room networking system, and can debug equipment remotely or on-site for customers, so that customer projects can be carried out smoothly.
service
It can provide one-stop service for passive optical network systems, provide professional consultation and answers to questions about GPON/EPON networking solutions for system integrators, assist customers in optimizing system networking solutions, save procurement time and procurement costs for customers, and get the best quality solutions for engineering projects.
Quality policy
With "perseverance in service, excellent quality and highly competitive cost, to meet customer needs" as its own quality policy, we always adhere to providing customers with high-quality products and services, and strive to obtain 100% customer satisfaction, and become a high-quality supplier worthy of customer trust and choice.
Quality control
The company has a complete testing system, and every equipment that leaves the factory has been tested and inspected. From the incoming material, production, testing, packaging and other processes of the product are quality control, the quality of the factory product is guaranteed to the greatest extent.
Our company's after-sales service has a dedicated line, and the supplier promises to provide free warranty within one year from the date of delivery due to product quality problems (not damage caused by improper use by users), lifelong maintenance (only maintenance costs are charged).
Company evaluation
Delivery Just-in-Time: 100%
Customer satisfaction > 95 points (quarterly)
Product Wholesale Pass-Through Rate>98% (Month)
Customer complaint rate<1% (month)
Corporate culture
Integrity-based, innovation as the soul, step by step, to build a reputable brand, think about what customers think, constantly surpass, and strive for perfection.
With the idea of "the next process is the user", we pay attention to professional ethics and professional responsibility, build a corporate image, create high-quality projects, be responsible for the project, and satisfy customers.
Factory Introduction
Our Certifications
The company focuses on the research, development, production, and sales of optical communication equipment. With years of experience in the optical communication field, it has a complete manufacturing system and quality control capabilities.
The company strictly adheres to national and international standards, fully obtaining China Compulsory Certification (3C) and other authoritative international certifications such as UL. Its product performance, safety indicators, electromagnetic compatibility, and environmental protection meet industry-leading levels, capable of satisfying market access and large-scale application needs both domestically and internationally.
Leveraging comprehensive qualification certifications, a mature supply chain system, and rigorous quality control standards, the company provides stable and reliable optical communication equipment for data centers, communication operators, and industrial communication sectors, earning widespread recognition from clients at home and abroad through compliant strength and quality assurance.
Shipping & Logistics
Global Shipping & Logistics
We have rich experience in export and global delivery. We work with reliable logistics partners to provide fast, safe and cost-effective shipping solutions worldwide, including sea freight, air freight and international express.
Before shipment, all optical communication products will be professionally packed and fully tested. We accept FOB, CIF, CFR, DDP and other delivery terms, ensuring your goods arrive on time and in good condition.
How to Pay
Frequently Asked Questions (FAQ)
Call to Action:
Ready to deploy a carrier-grade 1GE GPON ONU with proven OLT interoperability? [Contact our sales team] for a sample unit and comprehensive datasheet.
Headline: Reliability starts at the endpoint. Introducing our 1GE GPON ONU.
When deploying GPON FTTH, the last meter is just as important as the first mile. Our new 1GE GPON ONU ensures your customers experience the full 1 Gbps speed they pay for.
✅ ITU-T G.984 Compliant: Interoperable with Huawei, ZTE, Nokia OLTs.
✅ Class B+ Optics: Reliable performance up to 20KM.
✅ Gigabit LAN Port: No speed bottlenecks.
✅ Remote Management: Full OMCI support for zero-touch provisioning.
This GPON ONT is the smart choice for ISPs scaling their fiber footprint efficiently.
Interested in bulk pricing? Let's connect: [Link to Product Page]
#GPON #FTTH #ONU #ONT #FiberBroadband #ITU984 #TelecomEquipment #ISP #BroadbandAccess
3. FAQ :
Q: What is the difference between a 1GE GPON ONU and an XPON ONU?
A: A 1GE GPON ONU is a single-mode device that works only on GPON OLTs (ITU-T G.984). An XPON ONU contains firmware for both GPON and EPON and can auto-switch modes. For pure GPON networks, a dedicated GPON ONU often offers more stable OMCI interoperability and slightly lower cost due to optimized chipset design.
Q: Does this 1GE GPON ONU support Bridge Mode?
A: Yes. By default, this GPON ONU operates in Bridge Mode (Layer 2 Transparent Transmission), allowing the connected home router to handle PPPoE dialing and NAT. It can also be configured in Route Mode if you require the ONU itself to manage the WAN connection.
Q: Can I use this 1GE GPON ONU with a third-party OLT management system?
A: Absolutely. As long as your OLT vendor supports standard OMCI (G.988) provisioning, this GPON ONT can be discovered, configured, and managed remotely. We provide the necessary MIB (Management Information Base) files for integration.
Q: Is the power adapter included with the 1GE GPON ONU?
A: Yes. Each 1GE GPON ONU unit ships with a standard DC power adapter (typically 12V/0.5A) suitable for the destination country's plug type (US/EU/UK/AU options available upon request).
Q: What is the minimum order quantity (MOQ), and do you support small batch trial production?
A: The minimum order quantity for regular products is 500 units; for new customers, the trial production minimum order quantity can be negotiated to help you validate the market, and large-scale production can be adjusted according to the order size, flexibly adapting to your needs.
Q: Is it possible to customize product features, appearance, and specifications?
A: Sure. The appearance can be customized with your logo, color scheme, and packaging; functions and parameters can be adjusted according to your application scenarios (such as telecommunications, data centers, industrial communications). Whether it is hardware configuration or software debugging, it can be customized as needed to ensure the product fits your usage requirements.
Q: Production capacity and delivery cycle?
A: The factory has a monthly production capacity of 100,000 units. The delivery time for regular OEM orders is 7-15 working days. For large orders, production can be scheduled in advance, and a delivery guarantee agreement can be signed to ensure on-time delivery.
Q: Quality control standards and inspection procedures?
A: We follow the ISO9001 quality management system, perform full inspection on incoming raw materials, set up patrol inspections and semi-finished product tests during the production process, and complete comprehensive tests on finished products before shipment, including optical performance, high and low temperature, aging, and compatibility. Test reports are provided for each batch of orders to ensure a product pass rate of over 99.8% and compliance with industry standards.
Q: What is the product warranty period and after-sales policy?
A: All products come with a 1-2 year warranty (depending on the product type). Products that are not damaged by human factors within the warranty period can be repaired or replaced for free.
Q: What support is available for long-term cooperation?
A: Long-term cooperative customers can enjoy benefits such as priority scheduling, price discounts, free technical upgrades, and fast-track after-sales service. We will also provide product iteration suggestions based on market trends to help you continuously enhance your market competitiveness.
