1GE+3FE+2Voice WiFi XPON ONU | Dual Band Dual POTS ONT | GPON/EPON Triple-Play Terminal

Product Overview

The Flypon 1GE+3FE+2Voice Dual Band WiFi XPON ONU is a high-performance, feature-rich Optical Network Unit engineered for subscribers who demand multiple voice lines alongside premium wireless and wired connectivity. Supporting both GPON and EPON modes with intelligent auto-detection, this XPON ONU seamlessly integrates 1 Gigabit Ethernet port, 3 Fast Ethernet ports, 2 FXS voice ports, and a powerful dual-band WiFi module with 2 external high-gain antennas. It delivers ultra-fast internet, stable IPTV streaming, dual-line carrier-grade VoIP telephony, and whole-home dual-band wireless coverage—making it the ideal all-in-one CPE for SOHO environments, home offices, small retail locations, and multi-generation households requiring flexible voice and data services .

Key Features :

· XPON Dual Mode – Universal PON Compatibility: Built with an advanced dual-mode chipset that auto-detects and seamlessly transitions between GPON (ITU-T G.984) and EPON (IEEE 802.3ah) standards. One XPON ONU model serves both network architectures, dramatically simplifying inventory management, reducing SKU proliferation, and future-proofing deployments for operators with mixed or evolving PON infrastructures .

· Dual FXS Voice Ports – Two Independent Telephone Lines: Equipped with 2 FXS RJ11 ports, this XPON ONU supports two concurrent, independent telephone connections. Each port can be configured with separate SIP/H.248 credentials, different phone numbers, distinct codec preferences, and even different service providers. Ideal for home offices needing separate business and personal lines, retail environments requiring voice and fax simultaneously, or multi-line business applications .

· Dual-Band WiFi with 2 External High-Gain Antennas: Features 2 external 5dBi high-gain antennas delivering concurrent 2.4GHz + 5GHz dual-band WiFi. This WiFi XPON ONU achieves combined wireless speeds up to 1200Mbps (300Mbps on 2.4GHz + 867Mbps on 5GHz). With 2T2R MIMO technology and beamforming support, it provides reliable whole-home coverage—the 2.4GHz band ensures extended range and broad compatibility, while the 5GHz band delivers high-speed, low-interference connectivity for bandwidth-intensive applications like 4K streaming, video conferencing, and online gaming .

· Comprehensive Wired Connectivity Suite: The 1GE+3FE XPON ONU provides 1×10/100/1000Mbps GE port for gigabit-capable routers or high-performance devices, plus 3×10/100Mbps FE ports for IPTV set-top boxes, desktop PCs, network printers, surveillance systems, or other wired peripherals. Per-port VLAN tagging (802.1Q) and advanced QoS mechanisms ensure strict service isolation and traffic prioritization between data, voice, and video services .

· Carrier-Grade VoIP Telephony: Both FXS ports support SIP and H.248/MEGACO protocols, ensuring plug-and-play interoperability with leading softswitch platforms including BroadSoft, Huawei IMS, ZTE IMS, Metaswitch, and Genband. Full-featured voice capabilities include G.711/G.729/G.723/G.726 codecs, T.38/T.30 fax over IP, caller ID, call waiting, call forwarding, call transfer, three-way conferencing, and GR-909 line testing for proactive remote fault diagnosis. Each POTS port is independently configurable for maximum deployment flexibility .

· Advanced Remote Management & Zero-Touch Provisioning: Fully supports standard OMCI (ONT Management and Control Interface) for GPON deployments and OAM for EPON networks, enabling centralized remote configuration, bulk firmware upgrades, real-time performance monitoring, and rapid fault isolation. Optional TR-069 support allows seamless ACS integration for true zero-touch deployment, minimizing truck rolls and operational expenditures .

• Technical Specification




  1GE+3FE+2Voice Dual Band WiFi XPON ONU – Premium Dual-Line Triple-Play Fiber Gateway

  · Optical Interface: SC/APC or SC/UPC (Single Fiber)

  · XPON Standards: ITU-T G.984.x GPON / IEEE 802.3ah EPON

  · Data Rate: Up to 2.488 Gbps Down / 1.244 Gbps Up (GPON) / 1.25 Gbps Symmetric (EPON)

  · Wavelength: TX 1310nm, RX 1490nm

  · Optical Budget: Class B+ (28dB typical), Max Distance 20KM

  · User Interfaces:

    · 1 × 10/100/1000M RJ45 (GE Port)

    · 3 × 10/100M RJ45 (FE Ports)

    · 2 × FXS RJ11 (Voice Ports)

  · Wireless Specifications:

    · Standards: IEEE 802.11a/b/g/n/ac

    · Dual Band Concurrent: 2.4GHz + 5GHz

    · Combined Speed: Up to 1200Mbps (300Mbps @ 2.4GHz + 867Mbps @ 5GHz)

    · Antennas: 2 × 5dBi External High-Gain Antennas

    · MIMO: 2T2R with Beamforming Support

    · Security: WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPA3 (Optional)

    · Multi-SSID: Up to 4 SSIDs per band

    · Max Clients: 32+ Concurrent Users

  · VoIP Protocols: SIP (RFC 3261) / H.248 / MEGACO

  · Voice Codecs: G.711 a/μ-law, G.729, G.723.1, G.726, G.722

  · Fax Support: T.38 FoIP / T.30 G.711 Pass-through

  · Supplementary Services: Caller ID, Call Waiting, Call Forwarding, Call Transfer, Three-Way Conferencing, Do Not Disturb

  · Management: OMCI (GPON), OAM (EPON), TR-069 (Optional), Web GUI, Telnet, SSH

  · Power Consumption: < 9W

  · Operating Temperature: -5°C to 50°C

  · Operating Humidity: 10% to 90% RH (Non-condensing)

  · Dimensions: 185mm × 136mm × 34mm (L×W×H)

  · Net Weight: ~0.29Kg

  · Certifications: CE, RoHS, FCC (Optional)




Hardware Specification

Looking for a premium dual-voice, dual-band XPON ONU that delivers maximum flexibility for SOHO and multi-line subscribers? The 1GE+3FE+2Voice Dual Band WiFi XPON ONU is the all-in-one solution your network needs. [Contact our sales team] today for competitive volume pricing, sample evaluation units, and comprehensive interoperability documentation.

•


  Model	Description
  1GE+3FE+2Voice Dual Band WiFi XPON ONU	ONU,adaptor, packing box




  FAQ:

  Q: Can the two FXS ports on this XPON ONU operate with different VoIP service providers?

  A: Yes. Each FXS port on this XPON ONU operates as a fully independent SIP/H.248 endpoint. You can configure Port 1 with credentials from Provider A and Port 2 with credentials from Provider B, assign different phone numbers, use different codec profiles, and even have one port registered while the other remains on-hook—all on the same physical device. This provides maximum flexibility for SOHO and small business deployments .

  Q: How does the dual-band WiFi improve the user experience compared to single-band models?

  A: The dual-band WiFi XPON ONU operates simultaneously on both 2.4GHz and 5GHz bands. The 2.4GHz band provides extended range and better penetration through walls—ideal for basic browsing, email, and smart home devices. The 5GHz band offers significantly faster speeds (up to 867Mbps) with dramatically less interference from neighboring networks, microwaves, and Bluetooth devices—perfect for 4K streaming, Zoom/Teams video conferencing, online gaming, and large file transfers. This dual-band capability ensures every device gets the optimal connection for its needs .

  Q: Can the voice ports function independently when the ONU is in Bridge Mode?

  A: Absolutely. Even when the data channel is configured for Bridge Mode (where PPPoE authentication is handled by the subscriber's own router), both FXS voice ports operate autonomously and register directly with their respective VoIP softswitches. Voice and data services are logically isolated within the XPON ONU at both Layer 2 and Layer 3, ensuring all services function reliably without cross-interference .

  Q: Is this 1GE+3FE+2Voice XPON ONU compatible with my existing OLT infrastructure?

  A: Yes. This XPON ONU undergoes rigorous interoperability testing with OLTs from all major vendors, including Huawei (MA5600 series), ZTE (C300/C320 series), Nokia (7360 ISAM series), FiberHome (AN5500 series), Calix, ADTRAN, and VSOL. Standard OMCI (GPON) and OAM (EPON) protocols guarantee seamless discovery, configuration, and management in any standards-compliant PON environment .

  Q: Does this device support IPTV over WiFi, and how is it isolated from other traffic?

  A: Yes. The XPON ONU supports VLAN-to-SSID binding, allowing operators to create a dedicated SSID mapped exclusively to the IPTV VLAN. This enables wireless set-top boxes to receive IPTV streams on a logically separate network path that does not compete with general internet traffic. Additionally, 802.1p QoS tagging ensures video packets receive appropriate priority treatment for buffer-free viewing .

  Q: What fax capabilities are supported on the dual FXS ports?

  A: Both FXS ports fully support T.38 FoIP (Fax over IP) for reliable fax transmission over IP networks, as well as T.30 G.711 pass-through for compatibility with legacy fax machines. Each port can be independently configured with its own fax settings—for example, Port 1 optimized for a dedicated fax line with T.38, while Port 2 handles voice calls with G.729 compression. This makes the 2-voice XPON ONU ideal for businesses that rely on fax for orders, prescriptions, or legal documents .

  Q: What is the practical WiFi coverage area with the two external antennas?

  A: With 2×5dBi external high-gain antennas and 2T2R MIMO beamforming, this WiFi XPON ONU reliably covers apartments, home offices, and small business spaces up to approximately 100-120 square meters (1000-1300 square feet) . The dual-band design allows users to connect bandwidth-intensive devices to the cleaner 5GHz band while maintaining broad 2.4GHz coverage for legacy devices and IoT sensors .
